HEAVY DUTY INDUSTRIAL

H

Options (Not included)

80G

120G

240G

QR CODE

130648

AC100V~240V

Heavy Duty Variable Speed Shaft & Ferrule

Prepping Center.

"Newer is always better" especially when efficiency, flexibility,reliability

and safety can be seamlessly integrated in one net and powerful package!

Introducing our new shaft and prepping center with digital speed control,

that let a clubmaker set the most efficient speed for cutting steel and

graphite shafts, turn down ferrules and prep shaft tips at slower speeds to

prevent burn outs and flats and thus overcome all the pitfalls that only

experienced clubmakers have come to accept and managed to avoid!

Now with this new design, even novice clubmakers can manage to do a

descent job in half the time it takes to master the techniques that takes

years of practice.

42 Inch belts for prepping

and finishing shafts, ferrules

and clubheads.

FSR

FL

FLS

N264

FF

MG30

1306xFFC

Dry compound applied

in steps on felt belt used

SP-G0403- SP-G0403-

for buffing clubheads to

a mirror like finish

04HE-P10 04HY-P10

Functions and features:

-Compact design with small foot print.

-Combines shaft cutting, prepping and

ferrules turning into one easy package.

-Hi power 800 watts DC motor uses the

latest Mosfet / IGBT drive technology for

more power and less current consumption.

-Selection of fixed set speeds for cutting,

prepping and turning.

-Incremental 100 RPM speed control when

fixed speeds won't do.

-Stops from 3600 RPM to 0 in under 20 seconds!

-Power "ON" watch guard won't turn ON when

power is suddenly interrupted.

-Takes 5in high efficient cutoff discs (included)

-42x1in belts of assorted grit ( included)

-3" shaft tip prepping flap wheel (included)

-Dust extraction ports for vacuum cleaner

-Ferrule turning support arm (included)

-Spring loaded, floating belt drive mechanism

-Universal voltage 100~240V AC single phase.

-CSA/CUS/CE certified*

Flap Wheel SP-G0502

▲Pre-set

Speed control with 100

rpm increment. Chuncky E-Stop

brings the motor to a stop under

20 seconds.

▲Optimum

speed control for turning down ferrules and removing

thin film coating off graphite shafts without scuff marks. Trimiming

steel shafts with minimal wear on the cut off wheel produces less

dust and grit for a cleaner work bench.

▲Adjustable

turning arm with

thick & soft felt pads adds

smoothness to ferrule finishing.

* Certification Pending
