HEAVY DUTY INDUSTRIAL

H

QR CODE

030126

Manual SZP Frequency Analyser

This is the manual version of the APS Heavy Duty frequency analyzer

030126-HD. We’ve replaced the pneumatic cylinders with our torque

limited knobs so that club-makers that do not have access to an air

compressor can still perform advanced shaft zone profiling, with the

added benefit of the versatile clamp for securing shafts at 2,3,4 &

5"As well as gripped shafts.

Key features:

-New Auditor Engine with programmable profiling zones

-New Automatic shaft frequency averaging function

-On board data matrix capture, storage and batch transfer

-High accuracy +/- 1 CPM accuracy or 0.6 Hz

-Shaft frequency selectable digital filtering.

-High CPM capability +999 PM

▲New

shaft clamp with machined seats

provide excellent coupling with even

pressure distribution over the shaft

▲Split

clamp for securing shafts at

2,3,4,&5 inches.

Optional

Profiling Guide 030125-U1

-Shaft stop “look ahead” span indicator (1~11”)

-Pre-calibrated and easy to mount / take down.

▲New

Shaft frequency analysis engine.

▲Split

clamp is large enough for securing

Has auto reset and auto averaging function gripped clubs and oversize butt shafts.

and Programmable profiling zones.

▲Profiling

shaft stop with look ahead

span increment over a dual unit ruler
