Progressive Heavy Duty Shaft Extractor

The Golfmechanix Progressive shaft extractor is a design

engineered for maximum pulling power, with a low friction,

silky smooth stroking action that provides positive feedback

when extracting super light weight shafts and sophisticated

shaft adapters.

The new design uses our 700 Lbs pre-tensionning spring

mechanism which has proven reliabile and consistent when

extracting deep shafted bores over a broad range of Epoxy

& acrylic adhesives and working temperatures.

The spring pushing action is further enhanced by the

reduced drag offered by the screw’s recirculated ball

bearings resulting in a faster response to the applied heat.

The progressive shaft extractor can be bolted onto a work

bench or held in a vise.

210

310

210240

210225

▲Ball

screw requires 1/3 the torque

input on a conventional high count

lead screw to produce as much thrust

while lasting 3~4 times longer, the

equivalent of 8000+ shaft extractions.

▲Low

friction bronze bushing and

guides rod restrict and support the

jack nut when fully loaded .

Hosel gate accepts all shafts and

adapters up to .55”

▲The

high Shear, vulcanized rubber

jaws constricts shaft and distribute

pressure evenly . Jaws are easily

replaced.

Standard kit

Hosel protector 210225

Graphite tip extractor 210310

Ferrule splitter 210240

Adapter removal kit 210101

210101
