210116

Clubmaker’s compact Shaft Extractor

High load, low friction, low wear

trapezoidal thread and brass nut

produce the large mechanical

advantage and efficient transfer of

power needed to pin the shaft

down with minimal slippage.

▲Extractor

can be held in a

bench vis or mounted to work

bench

700 Lbs. Power spring pushes

against the hosel stopper,

liberating the head as soon as the

epoxy bond starts to break down

under the applied heat.

QR CODE

▲Gated

hosel stopper works

with most shafts and hosel

diameters

Option

1

2

Gated hosel stopper works with

most shafts and hosel diameters

1

Carbonitraded, low friction, hard,

wear resistant, high tensile

strength high thread count

machine screw produces a 300:1

mechanical advantage when

drawing shafts out Replacement

jack screw assembly: 210116-SK1

2

210116-SK1

SP-R04AV-75

Gated hosel stopper works with

most shafts and hosel diameters

The Clubmaker's Shaft Extractor with industrial performance is designed for smaller shops. It ticks all the

boxes for functionality, pulling power and serviceability.

This extractor has a full 5" throw for working on deep shafted wedges, hybrids and shafts with adapters,

while the gated hosel stopper has clearance for .335 .370 & .410 shaft tips.

To prevent weakening shafts that are to be re-used; A powerful 700 Lbs. compression spring embedded into

the hosel stopper pushes the club-head out as the epoxy bond disintegrates under the applied heat.

A judicious selection of materials, spec’s and processes put the clubmaker’s shaft extractor in a class all by

itself!

High Shear, vulcanized rubber jaws

constricts shaft over its circumfer-

ence, distributing pressure evenly.

While creating slippage inhibiting

friction over a larger surface area.

Spare rubber Jaws: SP-R04AV-75

Quick 1/4 turn ratcheting action,

provides leverage and speed and

reduces stress on the palm and

wrist. Wrench also fits on shaft

clamp nut doubling efficiency.
